Dallas公司官网 达拉斯代理商 达拉斯半导体代理商 电话0755-8397266O


Dallas公司美国达拉斯半导体公司(DALLAS Semiconductor Inc)，安富昌科技是达拉斯代理商，代理DALLAS半导体全系列产品。
Dallas半导体公司是Maxim公司的全资子公司。早在2001年,Dallas半导体已经被Maxim美信半导体公司收购,成为了Maxim公司的全资子公司。

Dallas半导体公司

Dallas达拉斯半导体公司成立于1984年,并以用户的问题为切入点来开发具有广泛用途的产品。其总部位于美国德克萨斯州,晶片工厂位于德州达拉斯城。

Dallas达拉斯半导体公司是一家设计、生产、销售一系列混合信号、专用半导体产品的公司。目前已发布了360多种专有的基本产品,产品广泛应用于宽带通信、无线手持设备、蜂窝基站、安全因特网通信、服务器、数据管理、医学和测试设备、家庭和商用设备及生产设备和网络控制系统的领域。

Dallas达拉斯目前公司的产品主要集中于三个战略方向:1.通讯:发展一系列符合现有各种通讯协议的高级程度芯片。2混合信号产品:包括NVSRAM、实时时钟、CPU监控电路、延迟线、数字电位器、热传感器、温度补偿晶体振荡器(TCXO)等。3.1-Wire&NetworkComputing:如微控制器产品。

Maxim半导体公司

美信集成产品公司(Maxim Integrated Products)成立于1983年,总部位于美国加利福尼亚的Sunnyvale。该公司在设计、发展、生产线性和混合信号集成电路产品方面处于世界领先地位。

在美国总部及世界各地均有分支机构。Mixim公司发布的模拟集成电路产品已超过1780种,处于同行业领先水平,其中1480多种产品是Mixim公司专有产品。其产品主要应用于微处理器类电子产品,包括个人计算机、测试设备、手持设备、无线通信产品及视频显示设备等。通过将诸如温度、压力、声音等现实世界的各种信号进行检测、放大和转换成计算机处理所需要的数字信号, Maxim的电路将现实世界与数字世界“连接”起来。

达拉斯芯片选型表



Memory (EPROM, EEPROM, ROM, NV SRAM)
型号与说明 Memory Type Memory Size Bus Type Real Time Clock DIP w/Int. Batt. Pwr. Cap Pckg. Battery Monitor GPIO VSUPPLY
(V)		 VSUPPLY
(V)		 RoHS Available Oper. Temp.
(°C)		 Package/Pins Smallest Available Pckg.
(mm2)		 Budgetary
Price
min max max w/pins See Notes
DS1220AB  16K Nonvolatile SRAM NV SRAM 2K x 8 Parallel No Yes No No No 4.75 5.25 See Data Sheet
-40 to +85
0 to +70
EDIP/24
609.6 $6.60 @1k
DS1220AD  16K Nonvolatile SRAM NV SRAM 2K x 8 Parallel No Yes No No No 4.5 5.5 See Data Sheet
-40 to +85
0 to +70
EDIP/24
609.6 $6.20 @1k
DS1225AB  64K Nonvolatile SRAM NV SRAM 8K x 8 Parallel No Yes No No No 4.75 5.25 Yes
-40 to +85
0 to +70
EDIP/28
629.9 $8.25 @1k
DS1225AD  64K Nonvolatile SRAM NV SRAM 8K x 8 Parallel No Yes No No No 4.5 5.5 Yes
-40 to +85
0 to +70
EDIP/28
629.9 $7.65 @1k
DS1230AB  256K Nonvolatile SRAM NV SRAM 32K x 8 Parallel No Yes Yes No No 4.75 5.25 Yes
-40 to +85
0 to +70
EDIP/28
PCAP/34
596.9 $8.54 @1k
DS1230W  3.3V 256K Nonvolatile SRAM NV SRAM 32K x 8 Parallel No Yes Yes No No 3 3.6 Yes
-40 to +85
0 to +70
EDIP/28
PCAP/34
596.9 $8.54 @1k
DS1230Y  256K Nonvolatile SRAM NV SRAM 32K x 8 Parallel No Yes Yes No No 4.5 5.5 Yes
-40 to +85
0 to +70
EDIP/28
PCAP/34
596.9 $8.61 @1k
DS1245AB  1024K Nonvolatile SRAM NV SRAM 128K x 8 Parallel No Yes Yes No No 4.75 5.25 Yes
-40 to +85
0 to +70
EDIP/32
PCAP/34
596.9 $12.54 @1k
DS1245W  3.3V 1024K Nonvolatile SRAM NV SRAM 128K x 8 Parallel No Yes Yes No No 3 3.6 Yes
-40 to +85
0 to +70
EDIP/32
PCAP/34
596.9 $12.54 @1k
DS1245Y  1024K Nonvolatile SRAM NV SRAM 128K x 8 Parallel No Yes Yes No No 4.5 5.5 Yes
-40 to +85
0 to +70
EDIP/32
PCAP/34
596.9 $12.54 @1k
DS1249AB  2048K Nonvolatile SRAM NV SRAM 256K x 8 Parallel No Yes No No No 4.75 5.25 See Data Sheet
-40 to +85
0 to +70
EDIP/32
707.2 $27.64 @1k
DS1249W  3.3V 2048K Nonvolatile SRAM NV SRAM 256K x 8 Parallel No Yes No No No 3 3.6 See Data Sheet
-40 to +85
0 to +70
EDIP/32
707.2 $27.64 @1k
DS1249Y  2048K Nonvolatile SRAM NV SRAM 256K x 8 Parallel No Yes No No No 4.5 5.5 See Data Sheet
-40 to +85
0 to +70
EDIP/32
707.2 $27.64 @1k
DS1250AB  4096K Nonvolatile SRAM NV SRAM 512K x 8 Parallel No Yes Yes No No 4.75 5.25 Yes
-40 to +85
0 to +70
EDIP/32
PCAP/34
596.9 $47.03 @1k
DS1250W  3.3V 4096K Nonvolatile SRAM NV SRAM 512K x 8 Parallel No Yes Yes No No 3 3.6 Yes
-40 to +85
0 to +70
EDIP/32
PCAP/34
596.9 $47.03 @1k
DS1250Y  4096K Nonvolatile SRAM NV SRAM 512K x 8 Parallel No Yes Yes No No 4.5 5.5 Yes
-40 to +85
0 to +70
EDIP/32
PCAP/34
596.9 $47.03 @1k
DS1265AB  8M Nonvolatile SRAM NV SRAM 1M x 8 Parallel No Yes No No No 4.75 5.25 Yes
-40 to +85
0 to +70
EDIP/36
861.6 $70.25 @1k
DS1265W  3.3V 8M Nonvolatile SRAM NV SRAM 1M x 8 Parallel No Yes No No No 3 3.6 Yes
-40 to +85
0 to +70
EDIP/36
861.6 $70.25 @1k
DS1265Y  8M Nonvolatile SRAM NV SRAM 1M x 8 Parallel No Yes No No No 4.5 5.5 Yes
-40 to +85
0 to +70
EDIP/36
861.6 $70.25 @1k
DS1270AB  16M Nonvolatile SRAM NV SRAM 2M x 8 Parallel No Yes No No No 4.75 5.25 Yes
-40 to +85
0 to +70
EDIP/36
861.6 $114.14 @1k
DS1270W  3.3V 16M Nonvolatile SRAM NV SRAM 2M x 8 Parallel No Yes No No No 3 3.6 Yes
-40 to +85
0 to +70
EDIP/36
861.6 $114.14 @1k
DS1270Y  16M Nonvolatile SRAM NV SRAM 2M x 8 Parallel No Yes No No No 4.5 5.5 Yes
-40 to +85
0 to +70
EDIP/36
861.6 $114.14 @1k
See All Memory (EPROM, EEPROM, ROM, NV SRAM) (66)




Non-Volatile RAM Controllers
型号与说明 CE Cntrl. Smart Socket w/Int. Batt. Li Batt. Monitor Pwr. Fail Out RAMs Controlled VSUPPLY
(V)		 RoHS Available Package/Pins Smallest Available Pckg.
(mm2)		 Oper. Temp.
(°C)		 Budgetary
Price
max w/pins See Notes
DS1210  Nonvolatile Controller Chip Yes No No No 1 5 Yes
PDIP(N)/8
SOIC(W)/16
81.9 - $2.44 @1k
DS1216B  SmartWatch/RAM Yes Yes No No 1 5 See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216C  SmartWatch/RAM Yes Yes No No 1 5 See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216D  SmartWatch/RAM Yes Yes No No 1 5 See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216H  SmartWatch/RAM Yes Yes No No 1 5 See Data Sheet
See Data Sheet/
- 0 to +70 $24.55 @1k
DS1218  Nonvolatile Controller Yes No No No 1 5 Yes
PDIP(N)/8
SOIC(N)/8
30.9 - $5.28 @1k
See All Non-Volatile RAM Controllers (11)




Timekeeping & Real-Time Clocks
型号与说明 Features Date/ Time Format Interface VSUPPLY
(V)		 Time Keeping Current
(nA)		 CL
(pF)		 Memory Type Memory Size
(Bytes)		 Time of Day Alarms Functions RoHS Available Package/Pins Smallest Available Pckg.
(mm2)		 Oper. Temp.
(°C)		 Budgetary
Price
hh = sec/100 typ max w/pins See Notes
DS1216B  SmartWatch/RAM Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - External RAM
2K
8K
0 NV SRAM Control See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216C  SmartWatch/RAM Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - External RAM
8K
32K
0 NV SRAM Control See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216D  SmartWatch/RAM Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - External RAM
8K
32K
0 NV SRAM Control See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216E  SmartWatch/ROM 64K Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - External ROM
8K
32K
0 ROM control See Data Sheet
See Data Sheet/
- 0 to +70 $19.94 @1k
DS1216F  SmartWatch/ROM 64K Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - External ROM
8K
32K
128K
0 ROM control See Data Sheet
See Data Sheet/
- 0 to +70 $21.48 @1k
DS1216H  SmartWatch/RAM Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - External RAM 512K 0 NV SRAM Control See Data Sheet
See Data Sheet/
- 0 to +70 $24.55 @1k
DS1243  64K NV SRAM with Phantom Clock Battery + Crystal YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
5 - - NV SRAM 8K 0 - Yes
EDIP/28
629.9 0 to +70 $11.75 @1k
DS1244  256K NV SRAM with Phantom Clock PowerCap Package YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
3.3
5
- - NV SRAM 32K 0 - Yes
EDIP/28
PCAP/34
596.9 0 to +70 $13.76 @1k
DS1248  1024K NV SRAM with Phantom Clock PowerCap Package YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
3.3
5
- - NV SRAM 128K 0 - Yes
EDIP/32
PCAP/34
596.9 -40 to +85 $17.08 @1k
DS1251  4096K NV SRAM with Phantom Clock PowerCap Package YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
3.3
5
- - NV SRAM 512K 0 - Yes
EDIP/32
PCAP/34
596.9 -40 to +85 $18.90 @1k
DS1254  2M x 8 NV SRAM with Phantom Clock PowerCap Package YY-MM-DD/ HH:MM:SS:hh
Bytewide
Phantom Clock
3.3 - - NV SRAM 2M 0 Clip-On Battery+Crystal Cap See Data Sheet
See Data Sheet/
- 0 to +70 $84.10 @1k
DS12885  Real Time Clock
Periodic Interrupt
Square-Wave Output
YY-MM-DD/ HH:MM:SS Multiplexed 5 225 6 NV SRAM 114 1 - Yes
PDIP(W)/24
PLCC/28
SOIC(W)/24
TQFP/32
84.6 -40 to +85 $2.97 @1k
DS12887  Real Time Clock
Battery + Crystal
Periodic Interrupt
Square-Wave Output
YY-MM-DD/ HH:MM:SS Multiplexed 5 - - NV SRAM 114 1 - Yes
EDIP/24
544.6 0 to +70 $4.70 @1k
DS12887A  Real Time Clock
Battery + Crystal
Periodic Interrupt
Square-Wave Output
YY-MM-DD/ HH:MM:SS Multiplexed 5 - - NV SRAM 114 1 - Yes
EDIP/24
544.6 0 to +70 $4.70 @1k
DS12C887  Real Time Clock
Battery + Crystal
Periodic Interrupt
Square-Wave Output
YYYY-MM-DD/ HH:MM:SS Multiplexed 5 - - NV SRAM 113 1 - Yes
EDIP/24
544.6 0 to +70 $4.70 @1k
DS12C887A  Real Time Clock
Battery + Crystal
Periodic Interrupt
Square-Wave Output
YYYY-MM-DD/ HH:MM:SS Multiplexed 5 - - NV SRAM 113 1 - Yes
EDIP/24
544.6 0 to +70 $4.76 @1k
DS12CR887  Real Time Clock
Battery + Crystal
Periodic Interrupt
Square-Wave Output
YY-MM-DD/ HH:MM:SS Multiplexed
3.3
5
- - NV SRAM 114 1 - Yes
EDIP/24
544.6 -40 to +85 $5.64 @1k
DS12R885  RTC with Constant Voltage Trickle Charger
Periodic Interrupt
Square-Wave Output
YY-MM-DD/ HH:MM:SS Multiplexed
3.3
5
800 12.5 NV SRAM 114 1 - Yes
SOIC(W)/24
166.1 -40 to +85 $1.65 @1k
DS12R887  RTC with Constant Voltage Trickle Charger
Battery + Crystal
Periodic Interrupt
Square-Wave Output
YY-MM-DD/ HH:MM:SS Multiplexed
3.3
5
- - NV SRAM 114 1 - No
BGA/48
180.5 -40 to +85 $6.12 @1k
See All Timekeeping & Real-Time Clocks (90)




Supervisors (1 Monitored Voltage)
型号与说明 Reset Thresh.
(V)		 Reset Out tRESET Watchdog Feature Watchdog Timeout Supervisor Features Reset Thresh. Accur.
(%)		 ICC
(µA)		 RoHS Available Oper. Temp.
(°C)		 Package/Pins Smallest Available Pckg.
(mm2)		 Budgetary
Price
min @ +25°C max max w/pins See Notes
DS1231  Power Monitor Chip 3.3 to 5.5
Active Low
Open Drain
85ms to 300ms No Watchdog - Power Fail Comparator/Low Battery Detect 2.5 2000 Yes
-40 to +85
0 to +70
PDIP(N)/8
SOIC(W)/16
79.7 $3.65 @1k
DS1232  MicroMonitor Chip 3.3 to 5.5
Active High
Active Low
Open Drain
Push-Pull
85ms to 300ms Input (WDI)
1s to 2s
<1s
Manual Reset 2.5 2000 Yes
-40 to +85
0 to +70
PDIP(N)/8
SOIC(W)/16
79.7 $1.17 @1k
DS1232LP  Low Power MicroMonitor Chip 3.3 to 5.5
Active High
Active Low
Open Drain
Push-Pull
85ms to 300ms Input (WDI)
1s to 2s
<1s
Manual Reset 2.5 50 Yes
-40 to +85
0 to +70
µMAX/8
PDIP(N)/8
SOIC(N)/8
SOIC(W)/16
15.6 $1.09 @1k
DS1233  5V EconoReset 3.3 to 5.5
Active Low
Open Drain
With Internal Pull-Up
250ms to 450ms No Watchdog - Manual Reset 2.5 50 Yes -40 to +85
SOT-223/3
TO92/3
19.5 $0.59 @1k
DS1233A  3.3V EconoReset 2.5 to 3.3
Active Low
Open Drain
With Internal Pull-Up
85ms to 300ms No Watchdog - Manual Reset 2.5 50 Yes -40 to +85
SOT-223/3
TO92/3
19.5 $0.69 @1k
DS1233D  5V EconoReset 3.3 to 5.5
Active Low
Open Drain
With Internal Pull-Up
85ms to 300ms No Watchdog - - 2.5 50 Yes -40 to +85
SOT-223/3
TO92/3
19.5 $0.72 @1k
DS1233M  EconoReset
2.5 to 3.3
3.3 to 5.5
Active Low
Open Drain
With Internal Pull-Up
85ms to 300ms
300ms to 1s
No Watchdog - - 2.5 50 Yes -40 to +85
SOIC(N)/8
TO92/3
19.5 $0.62 @1k
See All Supervisors (1 Monitored Voltage) (275)
